The Mac’s Vertical Home Lift PL-50
is designed and engineered for
everyday home use. It is easy to operate, easy to install and
virtually maintenance free. Every safety detail has been carefully
designed in the Mac’s Vertical Home Lift including a non-slip platform,
constant pressure switches, a low platform for easy access, safety ramp
and railing with all rolled edges. The Mac's Vertical Home Lift PL-50 is
built to meet and exceed residential applications uses common
household current and operates in all weather conditions, from -30
degrees to +120 degrees. The key-operated, constant pressure switch
enables you to start, stop and change directions at any point, unlike
many of the other lifts out there. The electrical system is placed well
above ground and sealed against moisture. The lift is finished with an
automotive grade powder coat to further protect the lift against the
elements. The Mac’s Vertical Home Lift PL-50 is sturdy
enough to lift and lower up to 750 lbs and will accommodate most
electric wheelchairs and scooters. In fact we ran a PL-50
with a full 750 lb load,continuously on a cycle that lifted and lowered
the platform 1 time a minute, 60 times an hour, 1,440 times a day with
no rest. That lift ran for 3 months, outside on our roof and completed
over 129,600 cycles without fail or need for maintenance. So if you were
to use this lift 1 time a day your lift would run for over 355 years
without a single lost day!You
will not find a better built product on the market for your money. We
are so sure of this that the Mac’s Vertical Home Lift PL-50
comes with a new 5 year limited warranty, another first for this
industry. With over 35 years experience of manufacturing residential
platform lift it is easy to see why a Mac’s Vertical Home Lift
PL-50 is your best and safest choice.
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Mac’s Vertical Home Lift
Technical Specifications MODEL: PL-50 and PL-72 SERIES: 750R
RATED LOAD: 750 lbs maximum NUMBER OF PASSENGERS: 1 passenger with
mobility equipment DRIVE: AC Powered lift: 1/2 hp instant reverse motor,
115 VAC, 5.9 amp DC Powered lift: 1/2 hp motor, 12 VDC INTERMEDIATE
REDUCTION: V belt and pulley FINAL DRIVE: #50 drive chain MOTOR
CONTROLLER: AC Powered lift: 24 VAC, 2 contactors; 1 up and 1 down DC
Powered lift: 12 VDC, 2 contactors; 1 up and 1 down STANDARD CONTROL:
Constant pressure paddle control with key switch SPEED: 10 feet per
minute LIFTING HEIGHT: Model PL-50 has a 51” maximum
lifting height Model PL-72 has a 72” maximum lifting height PLATFORM
SIZE: 32” x 48”, straight thru platform (standard) 36” x 54”, 90 degree
exit platform; LG 54 straight thru platform 36” x 60”, LG 90 degree exit
platform, LG 60 straight thru platform MAIN FRAME CONSTRUCTION: Formed
steel welded construction CARRIAGE CONSTRUCTION: Steel tubing and formed
channel welded construction PLATFORM CONSTRUCTION: 1” steel tubing
AUTOMATIC LOWER RAMP: 12” automatic lowering ramp MANUAL LOWERING
DEVICE: Standard. Manual hand crank to raise and lower lift FINISH:
Exterior grade powder coat paint, sandblast and primer LIMIT SWITCHES:
Adjustable upper final limit switch WEIGHT OF UNIT: Model PL-50R:
425 lbs Model PL-72R: 475 lbs |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Make Life Accessible Again with a Mac's Extended Vertical Lift
The Mac’s Extended Vertical Lift is designed and engineered for everyday
home use. It is easy to operate, easy to install and virtually
maintenance free. Every safety detail has been carefully designed in the
Mac’s Vertical Home Lift including a non-slip platform, constant
pressure switches, a low platform for easy access, safety ramp and
railing with all rolled edges. The drive system uses common
household current and operates in all weather conditions, from -30
degrees to +120 degrees. The key-operated, constant pressure switch
enables you to start, stop and change directions at any point, unlike
many of the other lifts out there. The electrical system is placed well
above ground and sealed against moisture. The lift is finished with an
automotive grade powder coat to further protect the lift against the
elements. The Mac’s Extended Vertical Lift is sturdy enough to
lift and lower up to 750 lbs and will accommodate most electric
wheelchairs and scooters. We have lifting heights available up to 107",
121", 134" and beyond. The highest we have manufactured to date is 168"
rise. The Mac’s Extended Vertical Lift is one tough, safe,
reliable and affordable lift. Compare it against all the competition.
You will not find a better built product on the market for your money.
We are so sure of this that the Mac’s Extended Vertical Lift comes with
a 2 year limited warranty. With over 35 years experience of
manufacturing residential platform lift it is easy to see why a Mac’s
Vertical Home Lift PL-50 is your best and safest choice.
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
MAX MODEL: PL-90
SERIES: 750R RATED LOAD: 750 lbs maximum NUMBER OF PASSENGERS: 1
passenger with mobility equipment DRIVE: AC Powered lift: 1/2 hp instant
reverse motor, 115 VAC, 5.9 amp DC Powered lift: 1/2 hp motor, 12 VDC
INTERMEDIATE REDUCTION: V belt and pulley FINAL DRIVE: #50 drive chain
MOTOR CONTROLLER: AC Powered lift: 24 VAC, 2 contactors; 1 up and 1 down
DC Powered lift: 12 VDC, 2 contactors; 1 up and 1 down STANDARD CONTROL:
Constant pressure paddle control with key switch SPEED: 10 feet per
minute LIFTING HEIGHT: Model PL-90 has a 90” maximum
lifting height PLATFORM SIZE: 32” x 48”, straight thru platform
(standard) 36” x 54”, 90 degree exit platform; LG 54 straight thru
platform 36” x 60”, LG 90 degree exit platform, LG 60 straight thru
platform MAIN FRAME CONSTRUCTION: Formed steel welded construction
CARRIAGE CONSTRUCTION: Steel tubing and formed channel welded
construction PLATFORM CONSTRUCTION: 1” steel tubing AUTOMATIC LOWER
RAMP: 12” automatic lowering ramp MANUAL LOWERING DEVICE: Standard.
Manual hand crank to raise and lower lift FINISH: Exterior grade powder
coat paint, sandblast and primer LIMIT SWITCHES: Adjustable upper final
limit switch WEIGHT OF UNIT: Model PL-90: 500 lbs |
